Briefly introduce the filter cartridge dust collector; characteristic
1. The dust inlet of the filter cartridge dust collector is equipped with a dust blocking plate, which has a buffering effect and prevents dust from directly impacting the filter cartridge at high speed, thus extending the service life of the filter cartridge.
2. The filter cartridge is installed in a 15 ° inclined drawer style, which makes it easy to remove and replace the filter cartridge. In addition, there are no transmission components in the dust collector body, which reduces maintenance work. For general dust, the filter cartridge can be used for a long time without the need for replacement, eliminating the tedious work of frequently changing and washing the filter bag in commonly used bag filters, and saving a lot of maintenance costs.
3. The dust collector adopts a sinking flow layout and an inclined filter cartridge structure, which results in good synchronous dust cleaning effect during operation.
4. Purification, with the above purification efficiency for dust particles above submicron, low operating resistance of equipment, and energy saving of dust removal system.
5. Modular combination, the size can be freely selected, and the original combination can be expanded to add dust removal units without requiring too many modifications to the original equipment.
On the basis of technology, the filter cartridge dust collector has been continuously improved and perfected in combination with the actual application situation in China. It is a bag filter with the characteristics of simple operation, continuous dust cleaning, stable resistance, high filtration speed, no internal moving parts, and simple design. Dust removal can capture dust above 0.1UM, purifying dusty gases to 15mg/m3 or even below. Less auxiliary equipment, lower investment, and lower technical requirements compared to electrostatic precipitators. It can capture dust that is difficult to recover from electrostatic precipitators, and to a certain extent, it can collect compounds such as nitrites and sulfides. Long service life and dust removal capability It can serve as a collector for fine dust and is also suitable for division filtration in various working conditions; It can solve the surface dust of wet and fibrous filter materials and has the advantage of high stripping rate. It has good adaptability to load changes, especially suitable for capturing fine and dry dust, and the collected dry dust is easy to handle and recycle.
