MKY pulse controller; It sends a pulse signal to control the pneumatic valve or solenoid valve, causing the pulse valve to spray light ash. The pulse signal generator is the main control device of the pulse bag filter, which uses a mechanical transmission device to directly trigger the pulse valves one by one for spraying.

Precautions for using MKY pulse controller:

1. Input voltage: 220V

2. Output voltage: AC110V/DC24V/AC220V Operating temperature: Temperature -20 ℃~50 ℃

3. Air temperature: ≤ 85%

4. The working environment is free from severe corrosive gases and conductive dust, and there is no severe vibration or impact

Technical specifications of MKY pulse controller:

1. Pulse width: 0.05-0.2 seconds 2. Pulse interval: 1-99 seconds

3. Cycle time: 0-250 minutes 4. Operating voltage: 220VAC-50HZ

5. Output current: 900mmA 6, output voltage: 24V, 110V, 220V optional

7. Environmental temperature:- 20℃< 45 ℃ 8. Environmental humidity:& gt;20%&& lt;80%。
